System Type: 15", 2-way, passive full-range speaker.
Low-Frequency Driver (Woofer): 15-inch 2265H Differential Drive woofer with a ferrite magnet, delivering deep and punchy low frequencies.
High-Frequency Driver (Tweeter): 3-inch diaphragm compression driver ( 2451H) featuring a ferrite magnet for crystal-clear, smooth high frequencies.
Power Rating:
Continuous Power: 800 Watts
Program Power: 1600 Watts
Peak Power: 3200 Watts
Nominal Impedance: 8 Ohms.
Frequency Range: 43 Hz – 20 kHz (-10 dB).
Frequency Response: 53 Hz – 20 kHz (+/-3 dB).
Maximum SPL: 131 dB SPL continuous (137 dB Peak), ensuring massive sound projection over long distances.
Coverage Pattern: 50 degrees x 50 degrees for precise, direct audio dispersion.
3. Design and Build Quality
Enclosure Material: Premium multi-ply birch plywood, offering an optimal balance of structural rigidity and reduced resonance.
Finish: Coated in rugged black Dura Flex finish, designed to resist scratches, dents, and heavy touring wear and tear.
Grille: Heavy-duty, 16-gauge perforated steel grille lined with acoustically transparent foam to protect the internal components from dust and damage.
Suspension Points: Built-in M10 threaded fly points for safe and easy permanent installation or rigging.
Handles: Heavy-duty steel handles integrated into the sides for comfortable lifting and transport.
Pole Mount: Dual-angle pole socket on the bottom to accommodate standard speaker stands or poles at different downward angles.
4. Key Features & Benefits
Lightweight Design: Thanks to advanced ferrite magnet technology, it weighs significantly less than traditional 15-inch speakers (approximately 48 lbs / 22 kg), making transport and setup much easier.
Distortion-Free High Output: Maintains exceptional clarity, balance, and vocal intelligibility even when pushed to high volumes.
Multi-Purpose Versatility: Can be used as a main PA speaker on poles, stacked over subwoofers, or laid on its side to serve as a high-performance floor monitor wedge.
